AC supply electric overhead crane travelling motor

Product Description

AC supply electric Overhead Crane travelling motor

Product Description

                                                                    I.Brief Introduction

YSE series three phase asynchronous motors, are the special design new motors according to the working requirement of Chain Hoist. YSE is single-speed, YDSE is double speed.

                                                                       II.Product Features
1. Motor housing is made of aluminum. Front and back end cover is aluminum die casting. Motor base is cold stretch aluminum piece. Whole aluminum housing motor, reduces the weight of the motor, also beneficial to the heat dissipation of the motor, so as to protects the motor winding is not easy to aging, extends the lifespan of the motor.

2. Motor adopts cold-rolled silicon steel sheet,( 55295468,which) enhances the motor performances of output power, the motor heat condition,starting torque, It is much better than hot-rolled silicon steel sheet.
                                                      III.Operation conditions:
1.Power Supply: rated voltage is 380V, rated frequency is 50Hz (other voltage and frequency can be customized).
2.protection grade IP54, insulation class F.
3.Work quota is S3-25%, 120 times per hour.
4.Motor should connect ground line, please refer to the power distribution regulations.
5.No rain and exposure , outdoor use should be packed with protective cover.


ATTENTION:Before the motor power supplied, please Use a 500-volt megohmmeter to measure the insulation resistor, the resistor should not be less than 0.5 megohms). Or should dry the motor. The drying temperature should not exceed 120 ℃.

Parameters



1> YSE motors (single speed):



Type Rated Power(KW) Frequency(HZ) Rated Voltage(V) Rated Currency(A) Rated Speed(r/min)
YSE801-2 0.4 50 380 1.35 2780
YSE802-2 0.8 50 380 2.3 2720
YSE90S-2 1.5 50 380 3.8 2760
YSE100L-2 4.0 50 380 10 2780



2> YSE motors (double speed):



Type Rated Power(kw) Frequency(HZ) Rated Voltage(V) Rated Currency(A) Rated Speed(r/min)
YSE801-2/8 0.4/0.1 50 380 1.35/1.3 2720/700
YSE802-2/8 0.8/0.2 50 380 2.3/1.8 2720/650
YSE90S-2 1.5/1.37 50 380 3.8/2.6 2820/690
YSE100L-2/8 4/1.0 50 380 10/8.7 2820/690



                                                 Motor shape and installation dimensions


Why Choose Vohoboo?


Company Information

Wuhan Vohoboo Import & Export Trade Co.,Ltd is a modern high technology enterprise integrated R&D, manufacture and sales since the year of 2011.



Our Products : Vohoboo specialized in the development and production of  DN hoist lifting motor, YSE crane traveling motor,( 55295469,CD/MD...)Electric Hoist, crane wheel, Crane Hook,CK car parking motor and so on, are widely used in electric hoist, Gantry Craneoverhead crane, Car Parking System and other lifting equipment.












FAQ

Q: What are you? Trade Company or manufacturer?
A: We are both manufacturer & trading company.

Q: What’s the advantage of your company?
A:We`re experienced manufacturer and overseas dealer.Our products have been exported to over 110 countries.An independent research team specially focusing on motors design and production. A professional service team for customers will provide feedback within 24 hours.

Q: What’s the sample & MOQ to your company?
A: Sample order MOQ can be 1 set and the product you ordered will be sent in a week as long as inventory is available.


Q:Can I customize the product according to my own willing?
A:Yes,we are high quality OEM/ODM manufacturer,we can satisfy all the requests to the product.

Q: How is the package during transportation?
A: 3 layers package. Outside is wood craft case. In the middle covered by foam to protect the motor from shaking. Inside layer covered by thickening plastic bag for waterproof.

Q: When the product can be delivered?
A: Commonly the lead time will be 7-10 working days after received deposit payment in our account.

Q: Will the package damaged during transportation?
A: Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe transportation. We have exported to 110 countries worldwide. So please don’t worry, you will receive the parcel in good condition.

Q: Can you customize the product according to my special requirement?
A: Yes,we are high quality OEM/ODM manufacturer. Any special requirement can be customized..

Q: What should I provide when inquiry?
A: The more information you provide, the accurate solution we can prepare for you!

1) Model we supplied or inform us where the motor will be used?

2) Rated power, rated voltage, rated frequency, speed?

3) Installation way?

4)Protection class, insulation class etc?
