High Quality Manual Wire Rope Hoist 0.5Ton To 5Ton

Product Description

 High Quality Manual Wire Rope Hoist 0.5Ton To 5Ton

Product Description

                                                    I.Product Introduction

It is a new and compact small size manual lifting tool. Light weight and firmed structure, widely used, convenient maintanence. The most attractive feature is can suit for outside and bad enviroment.



The outershell material is aluminum alloy, has engough strength, light weight and easliy carrying.

Insidde parts use best alloyed steel, with advaced technology, all parts through strickly checked and certification, even our main parts according to ISO standards to ensure our high quality.



                                                        II.Product Feature

1.Capacity: 0.8T x 20M, 1.6T x 20M, 3.2T x 20M, 5.4T x 20M. The lifting height can be customized.

2.All hoists are supplied complete with 20 meter wire rope and an extendable operating lever.

3.Wire rope is tapered one end and fitted with a hook and safety catch at the other end.

4.The hoist has low maintenance requirements and is easy service.

5.Overload protection ensures high personal safety when in operation.

6.Specially built-in shear pins can be replaced without removing the load.





                                                                 III.Product Package



Technical Parameters





Model Capacity(ton) Rated forward travel(mm) Rated forward hand power(N) wire rope Dia(mm) Wire rope safety factors(times) safety factor&static load capacity(v) Max travling load(kg) Net Weight(kg)
VB-0.8 0.8 >/52 341 8.3 5 5 1200 6.4
VB-1.6 1.6 >/55 438 11 5 5 2400 12
VB-3.2 3.2 >/28 438 16 5 5 4000 23
VB-5.4 5.4 >/30 850 20 5 5 8000 42
