High Speed Electric Winches (JK5T)

Product Description

Nante manufactures and exports superior quality electric winches for its valuable clients based at several parts of the world. Electric Winch is a device consisting of a horizontal cylinder turned back by a crank on which a cable or a rope wind is bound. These are compact and light weight material handling and lifting equipments, suitable for installation on cranes, davits and derricks.

Electric Winches are widely used in the following applications:
1. Cranes
2. Davits
3. Derricks
4. Marine
5. Punching driver
6. Construction Site and Port

Features:
1. The final drive gears are made of heat treated carbon steel that provides it a great strength.
2. It has an emergency crank handle.
3. Our product is available in AC and DC models also.
4. The front plate is made of stainless steel that provides a great rust resistance.
5. The die formed base of the equipment helps in quick mounting applications.
ModelRated LoadRated Rope SpeedLength of RopeRope Dia.Motor ModelPowerSizeTotal Weight
KNm/minmmmKWmmKG
JK0.55221107.5Y100L2-43710*690*490200
JK11022809.3Y112M-44710*610*410300
JK1.6162411512.5Y132S-45.5940*900*570500
JK2202411013Y132M-47.5940*900*570550
JK3.2323025015.5YZR180L-6151640*1430*8201150
JK5503024021.5YZR225M-6301900*1738*9852500
JK8803021026YZR280S-8451980*1790*11003500
JK101003030030YZR315S-8552250*2500*13005100

High Speed Electric Winches (JK5T)High Speed Electric Winches (JK5T)High Speed Electric Winches (JK5T)High Speed Electric Winches (JK5T)High Speed Electric Winches (JK5T)

Contact us if you need more details on Electric Winch. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Drum Winch、Trolley Winch. If these products fail to match your need, please contact us and we would like to provide relevant information.
