Ae Approved Truss Girder Goliath Crane
Product Description
AE Approved Truss Girder Goliath Crane
1. Steel structure part of the Gantry Crane is welded by U-steel with light weight, low cost and convenient assembly and disassembly.
2. Fast lifting speed and high wind resistance.
3. Many safety devices such as overload limiter, over-height limiter and overspeed switch are added to ensure products' safe operation.
4. We can design gantry cranes with different specifications to meet different customers' requirements.
1. Steel structure part of the Gantry Crane is welded by U-steel with light weight, low cost and convenient assembly and disassembly.
2. Fast lifting speed and high wind resistance.
3. Many safety devices such as overload limiter, over-height limiter and overspeed switch are added to ensure products' safe operation.
4. We can design gantry cranes with different specifications to meet different customers' requirements.
| Type | MGh32/5-23.4 |
|---|---|
| Lifting capacity | 32 t |
| Span | 23.4 m |
| Height | 10 m |
| Crane travelling speed | 20 m/min |
| Trolley moving speed | 20 m/min |
| Trolley lifting speed | 10m/min |
| Hoist lifting capacity | 5 t |
| Hoist lifting speed | 8 m/min |
| Power | 112 kw |
| Self-weight | 55 t |
