CD1 Electric Wire Rope Hoist
Product Description
CD1 Wire Rope Hoist
Product Description
1) Model: CD, MD, SH etc
2) Capacity: 1~10t
3) Hoisting height: 6~30m;
Product Feature
A. High efficiency and small handpull.
B. Light weight and easy handing
C. Fine appearance with small size
D. Durablilty in service
Application
Major application areas for Industry, factory, warehouse, wharf and dock, building construction sites etc.
crane is a machine used for lifting and lowering a load, and moving it horizontally. A crane's drives may be manual, powered or a combination of both. Cranes are typically used when there is insufficient (or intermittent) flow volume such that the use of a conveyor cannot be justified. They provide more flexibility in movement than conveyors, and less flexibility in movement than industrial trucks. Loads handled by cranes are more varied with respect to their shape and weight than those handled by a conveyor. Most cranes utilize hoists for vertical movement, although manipulators can be used if precise positioning of the load is required.
Many different types of cranes are used for material handling applications. These include overhead cranes as well as cherry picker type boom lifts, mobile and self-propelled cranes, straddle and counterbalanced (cantilevered) cranes. Portable and mobile floor cranes can be equipped with fixed or telescopic booms as well as mast rotation when equipped with outriggers. Lifting can be performed with the boom itself or a Winch operated cable lift.
Product Description
1) Model: CD, MD, SH etc
2) Capacity: 1~10t
3) Hoisting height: 6~30m;
Product Feature
A. High efficiency and small handpull.
B. Light weight and easy handing
C. Fine appearance with small size
D. Durablilty in service
Application
Major application areas for Industry, factory, warehouse, wharf and dock, building construction sites etc.
Capacity | Model | Working duty | Motor power(kW) | Hoisting speed(m/min) | NO. s of Chain | Chain line | Weight(kg) |
125 | shh-1-0.125 | m5 | 0.4 | 15 | 4 x 12 | 1 | 26 |
250 | shh-1-0.25 | m5 | 0.4 | 8 | 4 x 12 | 1 | 26 |
250 | shh-2-0.25 | m5 | 0.85 | 5 | 6.3 x 19 | 1 | 36 |
500 | shh-2-0.5 | m5 | 0.9 | 7.6 | 6.3 x 19 | 1 | 37 |
1000 | shh-2-1.0 | m4 | 1.1 | 5 | 8 x 24 | 1 | 40 |
2000 | shh-3-2.0 | m5 | 3 | 6 | 11.2 x 34 | 1 | 98 |
2500 | shh-3-2.5 | m5 | 3 | 5.2 | 11.2 x 34 | 1 | 100 |
3000 | shh-3-3.0 | m5 | 3 | 3~4 | 11.2 x 34 | 2 | 105 |
5000 | shh-3-5.0 | m4 | 3 | 2.6 | 11.2 x 34 | 2 | 120 |
10000 | 2 x shh-3-3.0 | m4 | 2 x 3 | 2.6 | 11.2 x 34 | 2 | 120 |
Many different types of cranes are used for material handling applications. These include overhead cranes as well as cherry picker type boom lifts, mobile and self-propelled cranes, straddle and counterbalanced (cantilevered) cranes. Portable and mobile floor cranes can be equipped with fixed or telescopic booms as well as mast rotation when equipped with outriggers. Lifting can be performed with the boom itself or a Winch operated cable lift.
